NIBCO T-585-70-HC_3/4 3/4" Threaded x MHT & Cap Ball Valve | T-585-70-HC Series

Nibco T-585-70-HC_3/4 Ball Valve

• Ball Valve
• Model T-585-70-Hc
• Type 2-Piece, Domestic
• Applicable Standard Iso 9001, Mss Sp-110
• Actuation Type Lever Handle
• Nominal Size 3/4 Inch X 3/4 Inch
• End Connection Female Threaded X Hose Cap And Chain
• End To End Distance 6.25 Inch
• Ball Material Astm 124 C37700 Brass Alloy
• Body Material Bronze
• Stem Material Astm B371 C69300 Silicon Bronze Alloy
• Seat Material Rptfe
• Seal Material Rptfe
• Handle Material Zinc Plated Steel
• Port Type Full
• Temperature Rating 400 Deg F
• Pressure Rating 600 Psi Cwp (Non-Shock)
• Inclusions/Features Blowout-Proof Stem, 3/4 Inch Hose Connection With Cap And Chain, 1/4 Turn, Rubber Gasket, Brass Chain, Di-Cast Brass Cap
• Application Commercial, Mechanical And Industrial
